JETI model Central Box 200 - Technical Specifications

EN
8 Technical specifications of the Central Box
Technical specifications of the Central Box 200
Recommended input voltage
4 – 14 V
Number of connectable accu cells
2-3 LiXX or 4-10 NiXX
Continuous current
15 A
Output pulse current
90 A
Number of servo outputs
up to 15
Consumption in the off state with magnetic switch
120uA
Consumption on the off state with the RC switch
140 uA
Operating temperature
- 20°C up to +75°C
Weight
30 g
Dimensions
63x38x17mm
Dimensions of magnetic switch
30x21x5 mm
Technical specifications of the Central Box 100
Recommended input voltage
4 – 14 V
Number of connectable accu cells
2-3 LiXX or 4-10 NiXX
Continuous current
10 A
Output pulse current
90 A
Number of servo outputs
up to 8
Operating temperature
- 20°C up to +75°C
Weight
20 g
Dimensions
52x25x11 mm
27 EN
