3.2 Overload protection of servos
The Central Box has an overload protection circuit on every servo
output. In case of an overload, the affected servo output is
disconnected from the power supply while the remaining servo
outputs are still powered.
Rsat2 (Rx1)
Rsat2 (Rx2)
7
Rx 1
Rx 2
Ext.
Out/In
BATT
8
8 channel servo interface
100100100
input
voltage
4-14V
Input Voltage 8.4V
SERVO High Voltage
Fig. 7: Example of the Central Box 100 powered for use with HIGH Voltage
servos
SERVO
SERVO
SERVO
NO
SERVO
NO
SERVO
YES
Fig. 8: Correct connection of servos to the Central Box
