computer radio control system
3.3 Binding
When using a new receiver or transmitter it is necessary to carry out
the binding process between them. Transmission between the
receiver and transmitter occurs in fully digital manner, therefore it is
necessary to identify and share the addresses of each device
communicating on the mutual 2.4GHz frequency band.
Procedure:
1. Insert the BIND PLUG (included in the receiver packing) into the
receiver socket labeled Ext.
2. Switch on the receiver  (connect a proper voltage supply to the
receiver). Binding of the receiver may now be performed within 60
seconds. After the 60 seconds elapse the receiver returns to setup
mode and the binding process must be repeated by starting again
from step 1.
3. Switch on the transmitter - the transmitter emits an acoustic
signal announcing the detection of a new receiver.
Binding may be carried out with the aid of the JETIBOX instead of
using the BIND PLUG.
The procedure is as follows:
1. Connect the JETIBOX with the connecting cable to the Ext.
receiver output .
2. Switch on the receiver - (connect a proper voltage supply to the
receiver).
3. The receiver menu appears on the JETIBOX display. Select the
Pairing menu item (push the right arrow button once from the
main receiver display) and then push the upward button. You now
have a period of 60 seconds to bind the receiver. After the 60
EN
10
JETI model s.r.o.
Lomená 1530, 742 58 Píbor
Czech Republic - EU
www.jetimodel.com
www.jetimodel.de
info@jetimodel.cz
Main Advantages of the
DUPLEX-System:
digital data transfer
system without crystals
safe operation
real time telemetric data transfer
two receiver antennas
response of receiver exits without time delay
simultaneous operation of several receivers
with one Tx module
acoustical signalling of the complete system
status
parameter set-up with the aid of the JETIBOX
terminal
Hauptvorteile des DUPLEX-Systems:
digitale Datenübertragung
System ohne Quarze
sicheres Betriebsverhalten
Übertragung von telemetrischen Daten in
Realzeit
zwei Empfängerantennen
ansprechen der Empfängerausgänge ohne
Zeitverzögerung
gleichzeitiger Betrieb mehrerer Empfänger
an einem Tx-Modul
akustische Signale geben Auskunft über den
Zustand des Systems
Parametereinstellung mit Hilfe des JETIBOX-
Terminals
Duplex-System EX:
Transmitter modules
Receivers
Telemetric sensors
Compatible accessories
Display units
Duplex-System EX:
Sendermodule
Empfänger
Telemetrische Sensoren
Kompatibles Zubehör
Abbildungseinheiten
radio control system
®
radio control system
extended serie
User Manual ... 01User Manual ... 01User Manual ... 01
Bedienungsanleitung ... 33Bedienungsanleitung ... 33Bedienungsanleitung ... 33
EN
DE
Receivers Receivers FW 3.22FW 3.22Receivers FW 3.22
Empfänger Empfänger FW 3.22FW 3.22Empfänger FW 3.22
