Jeti Duplex - Real Time Telemetry; 4.1 EX Telemetry; 4.2 1 st Generation Telemetry

computer radio control system
Every receiver is able to transmit the actual voltage supplied to the
on-board system (i. e. receiver voltage) without the need to connect
any additional external sensors. If you want to take advantage of
extended telemetry, connect a telemetry sensor to the Ext. input of
the receiver. If you want to operate several telemetry sensors
simultaneously with one receiver, you must use one or more of the
Expander EX devices, which , when connected to the Ext. receiver
input, gives you multiple inputs for telemetry sensors.
There are two ways to use JETI telemetry. The EX telemetry is
available to owners of the JETI DC/DS transmitters or the JETIBOX
profi. The 1st Generation Telemetry can be used by owners of the
TU, TG, TF etc. transmitter modules.
4.1 EX Telemetry
This telemetry data is displayed according to user selections in the
DC/DS transmitters and the JETIBOX profi. You will find more details
in actual instruction manuals of the given Duplex EX equipment.
4.2 - 1st Generation
Connect the JETIBOX to the transmitter module. Switch on the
transmitter and connect the receiver voltage supply (see chapter
Voltage supply). The Tx heading appears in the JETIBOX display
and by pressing the push-button R (right button) twice, select the
Mx menu. By pressing the push-button D (down) you will enter the
telemetry sensor or expander menu. You may leave the telemetry
sensor menu by pressing the push-button U(up) slightly longer.
4 Real time telemetry
EN
12
JETI model s.r.o.
Lomená 1530, 742 58 Píbor
Czech Republic - EU
www.jetimodel.com
www.jetimodel.de
info@jetimodel.cz
Main Advantages of the
DUPLEX-System:
 digital data transfer
 system without crystals
 safe operation
 real time telemetric data transfer
 two receiver antennas
 response of receiver exits without time delay
 simultaneous operation of several receivers
with one Tx module
 acoustical signalling of the complete system
status
 parameter set-up with the aid of the JETIBOX
terminal
Hauptvorteile des DUPLEX-Systems:
 digitale Datenübertragung
 System ohne Quarze
 sicheres Betriebsverhalten
 Übertragung von telemetrischen Daten in
Realzeit
 zwei Empfängerantennen
 ansprechen der Empfängerausgänge ohne
Zeitverzögerung
 gleichzeitiger Betrieb mehrerer Empfänger
an einem Tx-Modul
 akustische Signale geben Auskunft über den
Zustand des Systems
 Parametereinstellung mit Hilfe des JETIBOX-
Terminals
Duplex-System EX:
 Transmitter modules
 Receivers
 Telemetric sensors
 Compatible accessories
 Display units
Duplex-System EX:
 Sendermodule
 Empfänger
 Telemetrische Sensoren
 Kompatibles Zubehör
 Abbildungseinheiten
radio control system
®
radio control system
extended serie
User Manual ... 01User Manual ... 01User Manual ... 01
Bedienungsanleitung ... 33Bedienungsanleitung ... 33Bedienungsanleitung ... 33
EN
DE
Receivers Receivers FW 3.22FW 3.22Receivers FW 3.22
Empfänger Empfänger FW 3.22FW 3.22Empfänger FW 3.22
