computer radio control system
8.4 Receiver with the PPM output
- possibility to select PPM pos./neg.
- PPM output is on SAT2 output (if it exists), alternately SAT1 (if it
exists), alternately on the last servo output (then the number of
servo output is decreased by one) depending upon your
selected receiver
- the servo impulses are generated on the other servo outputs
- all the servo outputs are generated simultaneously during the
gap between PPM frames (outputs are then in one group)
8.5 Receiver with the PPM output in the function of
backup receiver (example of RSAT2 settings)
- PPM output is on SAT2 output (if it exist), alternately SAT1 (if it
exists), alternately on the last servo output (then the number of
servo outputs is decreased by one) depending upon your
selected receiver the servo impulses are generated on other
servo outputs
- all the servo outputs are generated simultaneously during the
gap between PPM frames (outputs are then in one group)
- no output repetition or fail safe is carried out. Every time the
receiver gets the data packet, output impulses and PPM burst
are generated once maximally
- if the data from the transmitter is not available for the receiver, all
the outputs are in Out-Off mode
28
JETI model s.r.o.
Lomená 1530, 742 58 Píbor
Czech Republic - EU
www.jetimodel.com
www.jetimodel.de
info@jetimodel.cz
Main Advantages of the
DUPLEX-System:
digital data transfer
system without crystals
safe operation
real time telemetric data transfer
two receiver antennas
response of receiver exits without time delay
simultaneous operation of several receivers
with one Tx module
acoustical signalling of the complete system
status
parameter set-up with the aid of the JETIBOX
terminal
Hauptvorteile des DUPLEX-Systems:
digitale Datenübertragung
System ohne Quarze
sicheres Betriebsverhalten
Übertragung von telemetrischen Daten in
Realzeit
zwei Empfängerantennen
ansprechen der Empfängerausgänge ohne
Zeitverzögerung
gleichzeitiger Betrieb mehrerer Empfänger
an einem Tx-Modul
akustische Signale geben Auskunft über den
Zustand des Systems
Parametereinstellung mit Hilfe des JETIBOX-
Terminals
Duplex-System EX:
Transmitter modules
Receivers
Telemetric sensors
Compatible accessories
Display units
Duplex-System EX:
Sendermodule
Empfänger
Telemetrische Sensoren
Kompatibles Zubehör
Abbildungseinheiten
radio control system
®
radio control system
extended serie
User Manual ... 01User Manual ... 01User Manual ... 01
Bedienungsanleitung ... 33Bedienungsanleitung ... 33Bedienungsanleitung ... 33
EN
DE
Receivers Receivers FW 3.22FW 3.22Receivers FW 3.22
Empfänger Empfänger FW 3.22FW 3.22Empfänger FW 3.22
