Jeti Duplex - 8.4 Receiver with the PPM Output

computer radio control system
8.1 Classic setup of a single receiver
(for any analogue/digital servos)
- servo impulses are generated on servo outputs
- each output can be assigned to one of the groups from A to H
- servo outputs assigned to one group are generated at the same
time
- between two consecutive servo groups there is a delay of 2.5ms
8 Examples of Rx setup
FailSafe
OutputPeriod
SerialLink
Rx mode
Enabled
17 ms
JETIBOX
Normal
8.2 Classic setup of a single receiver (for digital servos)
FailSafe
OutputPeriod
SerialLink
Rx mode
Enabled
Auto
JETIBOX
Normal
8.3 The second receiver as a backup (clone mode)
- monitors existing connection between the transmitter and the
receiver in "Normal" mode
- does not support telemetry (or an indication of the signal
strength)
- works in receiving direction only, it never transmits
- any number of receivers in Clone mode can be operated
simultaneously
FailSafe
OutputPeriod
SerialLink
Rx mode
Enabled
17 ms (or Auto)
JETIBOX
Clone
27
JETI model s.r.o.
Lomená 1530, 742 58 Píbor
Czech Republic - EU
www.jetimodel.com
www.jetimodel.de
info@jetimodel.cz
Main Advantages of the
DUPLEX-System:
 digital data transfer
 system without crystals
 safe operation
 real time telemetric data transfer
 two receiver antennas
 response of receiver exits without time delay
 simultaneous operation of several receivers
with one Tx module
 acoustical signalling of the complete system
status
 parameter set-up with the aid of the JETIBOX
terminal
Hauptvorteile des DUPLEX-Systems:
 digitale Datenübertragung
 System ohne Quarze
 sicheres Betriebsverhalten
 Übertragung von telemetrischen Daten in
Realzeit
 zwei Empfängerantennen
 ansprechen der Empfängerausgänge ohne
Zeitverzögerung
 gleichzeitiger Betrieb mehrerer Empfänger
an einem Tx-Modul
 akustische Signale geben Auskunft über den
Zustand des Systems
 Parametereinstellung mit Hilfe des JETIBOX-
Terminals
Duplex-System EX:
 Transmitter modules
 Receivers
 Telemetric sensors
 Compatible accessories
 Display units
Duplex-System EX:
 Sendermodule
 Empfänger
 Telemetrische Sensoren
 Kompatibles Zubehör
 Abbildungseinheiten
radio control system
®
radio control system
extended serie
User Manual ... 01User Manual ... 01User Manual ... 01
Bedienungsanleitung ... 33Bedienungsanleitung ... 33Bedienungsanleitung ... 33
EN
DE
Receivers Receivers FW 3.22FW 3.22Receivers FW 3.22
