Jeti Duplex User Manual

computer radio control system
5.1 Receiver setup via the JETIBOX
There are two receiver setup modes. The first is receiver setup via
the JETIBOX, JETIBOX Profi or JETIBOX emulation in the DC/DS
transmitters, the second one is direct setup of the receiver with a
DC/DS transmitter.
5.1.1 Direct connection between a JETIBOX and the
receiver
Insert one end of the connection cable (included with the JETIBOX)
into the socket labeled Impuls + - (see the right side of the JETIBOX)
and the other end into the receiver socket labelled Ext. Connect a
voltage supply to the receiver (see Voltage supply) or to the supply
socket of the JETIBOX. There is no need to supply voltage when
using the JETIBOX Profi.
5.1.2 Wireless connection between a JETIBOX with
transmitter or DC/DS transmitter and the receiver
In this case, connect the JETIBOX with the transmitter (if you are
using a DC/DS transmitter, then select the JETIBOX emulation).
Switch on the transmitter and then connect the receiver voltage
supply. The Tx heading appears on the display along with right and
down arrows. In order to enter the receiver, press the R button
(right), the Rx heading appears on the display and by subsequently
pressing the D button (down) you enter the receiver menu, which
will be displayed just the same as the direct connection mode (see
5 Receiver setup
EN
13
JETI model s.r.o.
Lomená 1530, 742 58 Píbor
Czech Republic - EU
www.jetimodel.com
www.jetimodel.de
info@jetimodel.cz
Main Advantages of the
DUPLEX-System:
 digital data transfer
 system without crystals
 safe operation
 real time telemetric data transfer
 two receiver antennas
 response of receiver exits without time delay
 simultaneous operation of several receivers
with one Tx module
 acoustical signalling of the complete system
status
 parameter set-up with the aid of the JETIBOX
terminal
Hauptvorteile des DUPLEX-Systems:
 digitale Datenübertragung
 System ohne Quarze
 sicheres Betriebsverhalten
 Übertragung von telemetrischen Daten in
Realzeit
 zwei Empfängerantennen
 ansprechen der Empfängerausgänge ohne
Zeitverzögerung
 gleichzeitiger Betrieb mehrerer Empfänger
an einem Tx-Modul
 akustische Signale geben Auskunft über den
Zustand des Systems
 Parametereinstellung mit Hilfe des JETIBOX-
Terminals
Duplex-System EX:
 Transmitter modules
 Receivers
 Telemetric sensors
 Compatible accessories
 Display units
Duplex-System EX:
 Sendermodule
 Empfänger
 Telemetrische Sensoren
 Kompatibles Zubehör
 Abbildungseinheiten
radio control system
®
radio control system
extended serie
User Manual ... 01User Manual ... 01User Manual ... 01
Bedienungsanleitung ... 33Bedienungsanleitung ... 33Bedienungsanleitung ... 33
EN
DE
Receivers Receivers FW 3.22FW 3.22Receivers FW 3.22
Empfänger Empfänger FW 3.22FW 3.22Empfänger FW 3.22
