computer radio control system
3.1 Voltage supply
When designing the on-board wiring for your project, always pay
attention to the voltage input range of your receivers and servos.
You can connect supply voltage to the Duplex receivers as
follows:
- directly from the batteries
- via a BEC voltage regulator (either contained in speed
controllers or self contained)
The supply may be connected to the Duplex receivers via:
- the throttle channel (when applying speed controllers with BEC)
- a free receiver output. Do not use the Ext. input for
connecting the voltage supply!
- a Y-cable to any arbitrary receiver output (other than the
Ext.)
- the MPX connector for receivers with the EPC label or the R14
and R18 receivers which are equipped with a power supply
connector
3.2 Operation
We recommend that you switch on the transmitter first and then
subsequently the receiver. The transmitter confirms the switching-
on of the receiver with an acoustic signal. When switching off the
system we recommend that you switch off the receiver first and
then subsequently proceed with switching-off the transmitter.
3 Overview
EN
9
JETI model s.r.o.
Lomená 1530, 742 58 Píbor
Czech Republic - EU
www.jetimodel.com
www.jetimodel.de
info@jetimodel.cz
Main Advantages of the
DUPLEX-System:
digital data transfer
system without crystals
safe operation
real time telemetric data transfer
two receiver antennas
response of receiver exits without time delay
simultaneous operation of several receivers
with one Tx module
acoustical signalling of the complete system
status
parameter set-up with the aid of the JETIBOX
terminal
Hauptvorteile des DUPLEX-Systems:
digitale Datenübertragung
System ohne Quarze
sicheres Betriebsverhalten
Übertragung von telemetrischen Daten in
Realzeit
zwei Empfängerantennen
ansprechen der Empfängerausgänge ohne
Zeitverzögerung
gleichzeitiger Betrieb mehrerer Empfänger
an einem Tx-Modul
akustische Signale geben Auskunft über den
Zustand des Systems
Parametereinstellung mit Hilfe des JETIBOX-
Terminals
Duplex-System EX:
Transmitter modules
Receivers
Telemetric sensors
Compatible accessories
Display units
Duplex-System EX:
Sendermodule
Empfänger
Telemetrische Sensoren
Kompatibles Zubehör
Abbildungseinheiten
radio control system
®
radio control system
extended serie
User Manual ... 01User Manual ... 01User Manual ... 01
Bedienungsanleitung ... 33Bedienungsanleitung ... 33Bedienungsanleitung ... 33
EN
DE
Receivers Receivers FW 3.22FW 3.22Receivers FW 3.22
Empfänger Empfänger FW 3.22FW 3.22Empfänger FW 3.22
