Jeti Duplex - 6.5 Auto Set

computer radio control system
6.4 Out pin set
Setup of the physical receiver outputs.
Set Output pin - selection of output, which goes for the following
setup. The menu item shows, as a decimal number, the throw of the
selected output. Receiver output 1 is labeled as Y1.
Some of the receivers outputs may be assigned (see the table of
receiver output assignments) to alternative functions. Description
of alternative functions:
- standard servo output - the throw of an actual channel is assigned
to the output that uses the standard servo output form and is
labelled CH xx.
- PPM off - for the given output there is no PPM signal generated or
received
- PPM input - for the given input there a PPM signal is expected from
the connected receiver
- PPM output - the receiver channel will generate a PPM signal
PPM error code- in case one of the SAT1/2 outputs is set to PPM
input mode, an acoustic signal can be set up to announce that this
connected signal is missing. By loading a character from the Morse
alphabet you may set up tones that will acoustically announce the
absence of a PPM signal at the given receiver output. This acoustical
signal is generated by the transmitter module. In the factory default
setup the acoustical signal is switched off.
SetInChannel - assignment of an actual output (labelled as Yx) or
input channel (labelled as Chx)
EN
21
JETI model s.r.o.
Lomená 1530, 742 58 Píbor
Czech Republic - EU
www.jetimodel.com
www.jetimodel.de
info@jetimodel.cz
Main Advantages of the
DUPLEX-System:
 digital data transfer
 system without crystals
 safe operation
 real time telemetric data transfer
 two receiver antennas
 response of receiver exits without time delay
 simultaneous operation of several receivers
with one Tx module
 acoustical signalling of the complete system
status
 parameter set-up with the aid of the JETIBOX
terminal
Hauptvorteile des DUPLEX-Systems:
 digitale Datenübertragung
 System ohne Quarze
 sicheres Betriebsverhalten
 Übertragung von telemetrischen Daten in
Realzeit
 zwei Empfängerantennen
 ansprechen der Empfängerausgänge ohne
Zeitverzögerung
 gleichzeitiger Betrieb mehrerer Empfänger
an einem Tx-Modul
 akustische Signale geben Auskunft über den
Zustand des Systems
 Parametereinstellung mit Hilfe des JETIBOX-
Terminals
Duplex-System EX:
 Transmitter modules
 Receivers
 Telemetric sensors
 Compatible accessories
 Display units
Duplex-System EX:
 Sendermodule
 Empfänger
 Telemetrische Sensoren
 Kompatibles Zubehör
 Abbildungseinheiten
radio control system
®
radio control system
extended serie
User Manual ... 01User Manual ... 01User Manual ... 01
Bedienungsanleitung ... 33Bedienungsanleitung ... 33Bedienungsanleitung ... 33
EN
DE
Receivers Receivers FW 3.22FW 3.22Receivers FW 3.22
Empfänger Empfänger FW 3.22FW 3.22Empfänger FW 3.22
