6 Receiver menu
6.1 Overview of receiver data items
The introductory display shows the receiver type. By pushing the R
key (arrow down) more detailed data of receiver and transmitter
can be displayed.
Pairing - by pushing the U key (arrow up) pairing of the receiver
with the transmitter will be executed. Pairing of the receiver should
only be carried out when JETIBOX is directly connected to the
receiver.
RX/TX- RX item shows the unic production number of the receiver.
The TX item shows the unique production number of the
transmitter, to which the receiver has eventually been paired.
Rx Diag- A1 or A2 item shows which antenna the receiver is using at
present. Kx item informs about the number of transferred channels
(this number depends on the transmitter abilities). By means of the
D key (arrow down) you arrive at the line of basic mode selections,
where you may select read out of measured values (Measure) or
setup of the receiver (Main setting, Out Pin Set, Auto Set).
