computer radio control system
Basic Data
R4
R4C
(R4C
mini)
R5L
R6
(R6
EPC*)
R7
(R7
indoor)
R8
(R8
EPC*)
Dimensions [mm]
35x 20x7
30x23x13
47x20x7
45x24x12
44x20x7
50x30x12
Weight [g]
4,8
8 (7)
5,4 (5)
11 (14)
5,5
15 (18)
Antenna length [mm]
2x100
1x200
(internal)
2x100
(2x45)
2x100
2x100
(2x45)
2x200
# of channel outputs
4
4
5
6
7
8
Temperature range [°C]
-10 to
+85
-10 to
+85
-10 to
+85
-10 to
+85
-10 to
+85
-10 to
+85
Supply voltage [V]
3.2  8.4
3.2  8.4
3.2  8.4
3.2  8.4
3.2  8.4
3.2  8.4
Average current [mA]
40
40
30
45
40
30
Real time transmission
of telemetry data
Yes
Yes
Yes
Yes
Yes
Yes
Programming
JETIBOX
JETIBOX
JETIBOX
JETIBOX
JETIBOX
JETIBOX
Support satellite receiver Rsat
no
no
no
no
no
no
Power output [dBm]
6
6
15
15
6
15
Receiver sensitivity [dBm]
-98
-98
-106
-106
-98
-106
2.1 Technical data of receivers outside the US part 1
2 Technical data
* xternal ower onnector E P C
EN
5
JETI model s.r.o.
Lomená 1530, 742 58 Píbor
Czech Republic - EU
www.jetimodel.com
www.jetimodel.de
info@jetimodel.cz
Main Advantages of the
DUPLEX-System:
digital data transfer
system without crystals
safe operation
real time telemetric data transfer
two receiver antennas
response of receiver exits without time delay
simultaneous operation of several receivers
with one Tx module
acoustical signalling of the complete system
status
parameter set-up with the aid of the JETIBOX
terminal
Hauptvorteile des DUPLEX-Systems:
digitale Datenübertragung
System ohne Quarze
sicheres Betriebsverhalten
Übertragung von telemetrischen Daten in
Realzeit
zwei Empfängerantennen
ansprechen der Empfängerausgänge ohne
Zeitverzögerung
gleichzeitiger Betrieb mehrerer Empfänger
an einem Tx-Modul
akustische Signale geben Auskunft über den
Zustand des Systems
Parametereinstellung mit Hilfe des JETIBOX-
Terminals
Duplex-System EX:
Transmitter modules
Receivers
Telemetric sensors
Compatible accessories
Display units
Duplex-System EX:
Sendermodule
Empfänger
Telemetrische Sensoren
Kompatibles Zubehör
Abbildungseinheiten
radio control system
®
radio control system
extended serie
