Jeti Duplex User Manual

computer radio control system
The legacy Duplex system was designed to give maximum
dependability, a property which has proven itself through many
successful years of use. Based on user input, the system is
continuously improved. Thanks to online updates the
improvements are easily accessible to users from any part of the
world. From the very beginning bidirectional transmission has
been a distinctive feature of the Duplex system, this not only
handles telemetry data, but it also helps to ensure secure primarily
transmission safety between the transmitter and receiver.
The Duplex EX telemetry system uses an open protocol. This gives
the advantage of compatibility with a large number of telemetry
sensors from both JETI model and third party producers. For the
display of telemetry data you can use purposely designed
equipment like the JETIBOX profi and DC/DS transmitters or you
can display the data on PCs with the free Flight Monitor program.
Although our development of the Duplex system seems to be very
fast, we make the extra effort to keep backward compatibility with
earlier Duplex versions. By design, users are not forced to
continually buy new equipment to take advantage of the latest
improvements.
The JETI model company portfolio contains a diverse offering of
electronic modelling equipment like voltage regulators, motor
speed controllers, telemetry data display equipment, telemetry
sensors and, last but not least, DC/DS transmitters. The JETI
model product manfacturing policy is to constantly produce the
highest quality product possible.
EN
4
JETI model s.r.o.
Lomená 1530, 742 58 Píbor
Czech Republic - EU
www.jetimodel.com
www.jetimodel.de
info@jetimodel.cz
Main Advantages of the
DUPLEX-System:
 digital data transfer
 system without crystals
 safe operation
 real time telemetric data transfer
 two receiver antennas
 response of receiver exits without time delay
 simultaneous operation of several receivers
with one Tx module
 acoustical signalling of the complete system
status
 parameter set-up with the aid of the JETIBOX
terminal
Hauptvorteile des DUPLEX-Systems:
 digitale Datenübertragung
 System ohne Quarze
 sicheres Betriebsverhalten
 Übertragung von telemetrischen Daten in
Realzeit
 zwei Empfängerantennen
 ansprechen der Empfängerausgänge ohne
Zeitverzögerung
 gleichzeitiger Betrieb mehrerer Empfänger
an einem Tx-Modul
 akustische Signale geben Auskunft über den
Zustand des Systems
 Parametereinstellung mit Hilfe des JETIBOX-
Terminals
Duplex-System EX:
 Transmitter modules
 Receivers
 Telemetric sensors
 Compatible accessories
 Display units
Duplex-System EX:
 Sendermodule
 Empfänger
 Telemetrische Sensoren
 Kompatibles Zubehör
 Abbildungseinheiten
radio control system
®
radio control system
extended serie
User Manual ... 01User Manual ... 01User Manual ... 01
Bedienungsanleitung ... 33Bedienungsanleitung ... 33Bedienungsanleitung ... 33
EN
DE
Receivers Receivers FW 3.22FW 3.22Receivers FW 3.22
Empfänger Empfänger FW 3.22FW 3.22Empfänger FW 3.22
