Jeti Duplex User Manual

computer radio control system
Basic Data
R4L
(R4L indoor)
R5L
(R5L indoor)
R6L
(R6L indoor)
R7plus
Dimensions [mm]
38x20x7
47x20x7
43x24x11
51x24x11
Weight [g]
4,8 (4,5)
5,4 (5)
13
13
Antenna length [mm]
2x100 (2x45)
2x100 (2x45)
2x200 (2x50)
2x200
# of channel outputs
4
5
6
7
Temperature range [°C]
-10 to +85
-10 to +85
-10 to +85
-10 to +85
Supply voltage [V]
3.2  8.4
3.2  8.4
3.2  8.4
3.2  8.4
Average current [mA]
30
30
30
30
Real time transmission of
telemetry data
No
Yes
Yes
Yes
Programming
Tx
JETIBOX
JETIBOX
JETIBOX
Support satellite receiver Rsat
No
No
No
Yes
Power output [dBm]
15
15
15
15
Receiver sensitivity [dBm]
-106
-106
-106
-106
2.2 Technical data of receivers for the US part 1
* xternal ower onnector E P C
EN
7
JETI model s.r.o.
Lomená 1530, 742 58 Píbor
Czech Republic - EU
www.jetimodel.com
www.jetimodel.de
info@jetimodel.cz
Main Advantages of the
DUPLEX-System:
 digital data transfer
 system without crystals
 safe operation
 real time telemetric data transfer
 two receiver antennas
 response of receiver exits without time delay
 simultaneous operation of several receivers
with one Tx module
 acoustical signalling of the complete system
status
 parameter set-up with the aid of the JETIBOX
terminal
Hauptvorteile des DUPLEX-Systems:
 digitale Datenübertragung
 System ohne Quarze
 sicheres Betriebsverhalten
 Übertragung von telemetrischen Daten in
Realzeit
 zwei Empfängerantennen
 ansprechen der Empfängerausgänge ohne
Zeitverzögerung
 gleichzeitiger Betrieb mehrerer Empfänger
an einem Tx-Modul
 akustische Signale geben Auskunft über den
Zustand des Systems
 Parametereinstellung mit Hilfe des JETIBOX-
Terminals
Duplex-System EX:
 Transmitter modules
 Receivers
 Telemetric sensors
 Compatible accessories
 Display units
Duplex-System EX:
 Sendermodule
 Empfänger
 Telemetrische Sensoren
 Kompatibles Zubehör
 Abbildungseinheiten
radio control system
®
radio control system
extended serie
User Manual ... 01User Manual ... 01User Manual ... 01
Bedienungsanleitung ... 33Bedienungsanleitung ... 33Bedienungsanleitung ... 33
EN
DE
Receivers Receivers FW 3.22FW 3.22Receivers FW 3.22
Empfänger Empfänger FW 3.22FW 3.22Empfänger FW 3.22
