computer radio control system
8.6 Receiver with the EX Bus output
- suitable especially for connection to JETI model devices (such as
Central Box)
- EX Bus is present at Ext. receiver connector and the telemetry
sensors are then connected to the nearest EX Bus expander (e.g.
Central Box)
- after the receiver is switched on (with the transmitter turned off)
it is possible to connect JETIBOX to the receiver via Ext.
connector. After the transmitter is switched on, the serial
protocol on Ext. connector changes to EX Bus and the
configuration using connected JETIBOX is not possible until the
transmitter is switched off or the Rx mode is changed.
8.7 Receiver with the UDI output
- suitable for connection of devices with unidirectional UDI
interface (e.g. VBar)
- UDI output is present on SAT2 output (if it exists), alternately
SAT1 (if it exists), alternately on the last servo output (then the
number of servo outputs is decreased by one) depending upon
your selected receiver
- the servo impulses are generated on other servo outputs it is
possible to connect telemetry sensors to the Ext. connector as
usual
29
JETI model s.r.o.
Lomená 1530, 742 58 Píbor
Czech Republic - EU
www.jetimodel.com
www.jetimodel.de
info@jetimodel.cz
Main Advantages of the
DUPLEX-System:
digital data transfer
system without crystals
safe operation
real time telemetric data transfer
two receiver antennas
response of receiver exits without time delay
simultaneous operation of several receivers
with one Tx module
acoustical signalling of the complete system
status
parameter set-up with the aid of the JETIBOX
terminal
Hauptvorteile des DUPLEX-Systems:
digitale Datenübertragung
System ohne Quarze
sicheres Betriebsverhalten
Übertragung von telemetrischen Daten in
Realzeit
zwei Empfängerantennen
ansprechen der Empfängerausgänge ohne
Zeitverzögerung
gleichzeitiger Betrieb mehrerer Empfänger
an einem Tx-Modul
akustische Signale geben Auskunft über den
Zustand des Systems
Parametereinstellung mit Hilfe des JETIBOX-
Terminals
Duplex-System EX:
Transmitter modules
Receivers
Telemetric sensors
Compatible accessories
Display units
Duplex-System EX:
Sendermodule
Empfänger
Telemetrische Sensoren
Kompatibles Zubehör
Abbildungseinheiten
