Jetmaster 18f - Fitting the Log Retainer; Fitting the Ash Pan; Fitting the Rear Heat Shield (Optional Extra)

Fitting the Log Retainer
The log retainer is attached at the front of the stove by sliding down between the slots at each side at the front.
Theretainershouldbettedthecorrectwayaroundasshowninthediagram.
Fitting the Ash Pan
Fittheashpanbyslidinginunderthebottomgrateboard.Ensureitisttedthecorrectwayaroundwiththe
handle towards the front as shown below.
Fitting the rear Heat Shield (Optional Extra)
Therearheatshieldisttedtotherearofthestovebyclippingtheslotsoverthereboxboltslocatedeachside
at the top and bottom of the rear of the stove.
Heat Shield Locating Slot
Top Bolt Bottom Bolt
