Jetmaster 18f - Protection of Heat

Lifttheshieldhigherthanthestove,pushtowardsthestoveandthenpushdownlocatingtheslotovertherebox
bolts. If the shield cannot be engaged then adjust the bolts by unscrewing outwards or screwing inwards slightly
soastheshieldtscorrectly.Finallytightentheboltstoxtheheatshieldtothestovebody.
Ensure that the shield is not pressed tight against any combustible surface. Ensure correct distance away from
rear of combustible material as shown.
Protection of Heat
Aheatshieldisavailableasanoptionalextra.Tottheheatshieldseesectionon“ttingtherearheatshield”.
Thedistancetocombustiblematerialwillbereducedwhentheheatshieldistted.
Rear Rear Heat
Model No Heat Shield Shield Fitted
Sides Back Sides Back
18f 600mm 800mm 600mm 250mm
60f - - - -
19
Combustible Wall
Heat Shield
Stove
250mmwithHeatShieldtted
