2. PULL THE FRONT FRAME FROM THE REAR FRAME UNTIL KNOB HOLES ARE ALIGNED WITH THE LAST OF FOUR HOLES IN BOTH
FRAME CONNECTOR BARS.
3. FROM THE TOP, INSERT 1 KNOB INTO EACH SET OF ALIGNED HOLES BY TWISTING IT IN CLOCKWISE. CONTINUE TURNING
BOTH KNOBS UNTIL THE TIPS EMERGE ON THE UNDERSIDE OF THE CONNECTOR BAR AND THE KNOBS ARE TIGHT.
4. CHECK THAT THE FRAME IS SECURE.
NOTE: AFTER COMPLETING ASSEMBLY, SET THE FRAME TO THE DESIRED LENGTH BY REMOVING THE KNOBS,
SHORTENING OR LENGTHENING THE FRAME, AND REINSERTING THE KNOBS INTO THE DESIRED SET OF ALIGNED
HOLES ON THE FRAME CONNECTOR BARS.
FRONT FRAME
REAR FRAME
FRAME
CONNECTOR BAR
2
3
