Jetson Volt X - Assembling the Front Axle

18
2.3 Assembling the Front Axle
YOU WILL NEED THE PHILLIPS-HEAD SCREWDRIVER.
1. HOLD THE PRE-INSTALLED NUT(SIZE M6) ON THE STEERING BRACKET STEADY. LOOSEN AND REMOVE THE PRE-INSTALLED
BOLT(SIZE M6 X 13MM) BY TWISTING IT OUT COUNTERCLOCKWISE WITH THE PHILLPS-HEAD SCREWDRIVER. SET THE BOLT
AND NUT ASIDE.
PHILLIPS-HEAD
SCREWDRIVER
NUT
STEERING
BRACKET
BOLT
