Jetson Volt X - Attaching the Rear Wheels

33
YOU WILL NEED BOTH SOCKET WRENCHES.
1. LOOSEN AND REMOVE THE 2 PRE-INSTALLED AXLE NUTS(SIZE M8) FROM THE REAR AXLE (G) BY TWISTING EACH OFF
COUNTERCLOCKWISE WITH A SOCKET WRENCH. SLIDE THE 2 PRE-INSTALLED MEDIUM WASHERS (M8 X 22 MM X 1.3 MM)
OFF OF THE REAR AXLE. SET THE HARDWARE ASIDE.
2.7 Attaching the Rear Wheels
REAR AXLE (G)
AXLE NUT
AXLE NUT
WASHER
WASHER
