Jetson Volt X - Installing the Front Guard

23
YOU WILL NEED THE PHILLIPS-HEAD SCREWDRIVER AND 3 MEDIUM SCREWS (S2).
1. HOLD THE FRONT GUARD (C) ABOVE THE FRONT OF THE FRAME (A).
2. MAKE THE ELECTRICAL CONNECTION BY CLICKING THE INSERTION COUPLER ON THE WIRES AT THE BASE OF THE FRONT
GUARD INTO THE RECEIVING COUPLER ON THE WIRES AT THE FRONT OF THE FRAME.
IMPORTANT: HANDLE ELECTRICAL COMPONENTS WITH CAUTION.
2.5 Installing the Front Guard
FRONT GUARD (C)
FRAME (A)
1
2
COUPLERS
