24
3. ALIGN THE 3 TABS AT THE BASE OF THE FRONT GUARD (C) WITH THE 3 TAB SLOTS AT THE FRONT OF THE FRAME (A).
4. WHILE TUCKING THE COUPLERS AND WIRES INTO THE WIRE CAVITY OF THE FRAME, CLICK THE TABS OF THE FRONT GUARD
INTO THE TAB HOLES IN THE FRAME.
IMPORTANT: ENSURE THAT NO WIRING IS EXPOSED OUTSIDE OF THE FRAME OR FRONT GUARD.
TAB
TAB SLOT
WIRE CAVITY
FRONT GUARD (C)
FRAME (A)
