Jetson Volt X - Installing the Seat; Battery Compartment

43
YOU WILL NEED THE PHILLIPS-HEAD SCREWDRIVER AND 2 MEDIUM SCREWS (S2).
1. POSITION THE SEAT (L) ABOVE THE FRAME (A) SUCH THAT:
• THE SEATBELT STRAPS ARE ON TOP OF THE SITTING AREA.
• THE SEAT BACK IS VERTICAL.
• THE SEAT BACK IS AT THE REAR OF THE PASSENGER AREA.
2. PLACE THE SEAT IN THE FRAME SO THAT THE SCREW HOLES IN
THE SEAT BACK ARE IN LINE WITH THE SCREW HOLES IN THE
FRAME IN FRONT OF THE BATTERY COMPARTMENT.
2.9 Installing the Seat
SEAT (L)
FRAME (A)
BATTERY
COMPARTMENT
SEATBELT
