Jetson Volt X - Connecting the Battery

45
1. FROM THE 2 SETS OF WIRES IN THE BATTERY
COMPARTMENT, MAKE THE ELECTRICAL CONNECTION
BY CLICKING THE INSERTION COUPLER INTO THE
RECEIVING COUPLER.
IMPORTANT: HANDLE ELECTRICAL COMPONENTS
WITH CAUTION.
2.10 Connecting the Battery
COUPLERS
BATTERY
COMPARTMENT
