34
2. POSITION THE FRAME (A) RIGHT SIDE UP.
3. FROM ONE SIDE OF THE FRAME, SLIDE THE REAR AXLE (G) THROUGH THE REAR AXLE CHANNEL UNTIL THE TIP EMERGES ON
THE OTHER SIDE OF THE FRAME.
FRAME (A)
REAR AXLE (G)
REAR AXLE CHANNEL
