Jetson Volt X - Page 50

48
7. INSERT THE 2 TABS AT THE FRONT OF THE BATTERY COMPARTMENT COVER (M)INTO THE 2 SLOTS ON THE BACK SIDE OF
THE SEAT BACK.
8. ATTACH THE BATTERY COMPARTMENT COVER TO THE BATTERY COMPARTMENT BY CLICKING THE 3 TABS ON THE
UNDERSIDE OF THE BATTERY COMPARTMENT COVER INTO THE 3 TAB SLOTS IN THE BATTERY COMPARTMENT.
SEAT BACK
SEAT BACK TAB
SLOT (X2)
BATTERY
COMPARTMENT
TAB SLOT (X3)
BATTERY
COMPARTMENT
