JETSURF RACE TITANIUM - Fuel Mixing; Fuel Tank Removal; Fuel Top-Up; Safe Operation on the Water..... 18 |6| Storage

34 35
3) Undo the velcro on the tank – FIGURE 3.
4) Move the tank out upwards – FIGURE 4.
FUEL TOP-UP
Observe all the safety instructions specied in this manual.
NEVER add fuel into the tank which is inside the JetSurf™. Before adding
fuel, ALWAYS take the tank out.
FUEL MIXING
Make sure that petrol and oil are mixed properly in the correct propor-
tion. If the proportion is not observed, the engine may get damaged.
FUEL TANK REMOVAL
Observe all the safety instructions specied in this manual.
1) Disconnect the rst CPC coupling connecting the tube coming out of the tank and the blue tube
going into the snorkel – FIGURE 1. The CPC coupling has a security clip which must be pressed
when disconnected.
2) Disconnect the second CPC coupling connecting the tube coming out of the tank to the tube going
to the carburettor – FIGURE 2. The CPC coupling has a security clip which must be pressed when
disconnected.
FIGURE 1FIGURE 1 FIGURE 2FIGURE 2
FIGURE 1FIGURE 3 FIGURE 2FIGURE 4
DESCRIPTION OF PARTSDESCRIPTION OF PARTS
PETROL TO OIL
MIXTURE
50 parts of
petrol
1 part of oil
Example:
To 1 litre of petrol
add 0.02 l (20 ml) of oil
To 2 litres of petrol
add 0.04 l (40 ml) of oil
WARNING
50 : 1
