34
PERIODIC INSPECTION AND ADJUSTMENT
When unable to adjust the cable on the throttle handle,
adjust the adjuster on the carburetor.
The second step (carburetor)
Loosen the lock screw cap
Adjust the adjustor
Note
Turn in The clearance is increased
Turn out
The clearance is decreased
Tighten the lock screw cap
Warning
Out of specification Adjust side the electric pole
The clearance between the electric poles
0.6~0.7mm
Standard spark plug: A6RTC/CR6HSA
Check the spark plug
1. Check
Check electrode, insulation pollution, burning loss,
deposit loss
Replace
Pollution, deposit Clean it with some spark plug
detergent and a wire brush.
2. Measure the clearance of the central electric pole
and the side electric pole .
******************************************
After adjusted, start the engine, turn the steering bar
from the left to the right, and confirm the engine idle
speed will not rise.
