PERIODIC INSPECTION AND ADJUSTMENT
47
Check front fork
1. Place the machine in a level place
2. Check
Front fork vertical rod
Scratch or damage
Replace
Oil seal
Serious leakage
Replace
3. Maintain the machine in vertical position, catching
the front brake.
4. Check
Operation
Slide the front fork up and down several times.
Stuck
Repair
Refer to
Front fork in chapter 6
Adjust rear shock absorber
Warning
Caution
Must adjust each absorber's preloaded values to
uniform set value to avoid worsening operability and
reducing stability.
Support the machine firmly to prevent it from turn
over.
The adjusting advice mustn't turn
to a minimum
position or a maximum position.
Turn to the direction
The spring preloaded
value is increased.
Turn to the direction
The spring preloaded
value is decreased.
Adjusting advice:
Standard:3 Min :1 Max :5
1. Adjust
Spring preload
Turn adjusting advice
to the direction or .
