JIYI K++ User Manual

Note: In dual-pump mode, the forward movement of the aircraft is controlled by the
P1 port and the backward movement is controlled by the P2 port.
2) .Channel setting
The mapping channel is used to select the channel that the remote
control controls the pump. The default is 7 channels. The user can
set it according to the remote control.
4. Liquid level gauge
Click to enter the advanced interface of the assistant software, and
select the level gauge in the upper menu bar, as shown in the figure,
the level gauge type is selected, the current level gauge status and
the drug protection setting.
1). Type of liquid level gauge:
The switch level gauge needs to be connected to the flight control
L1 port. Users connected to the flight control can choose to use or
not use the switch level gauge according to their needs.

JIYI K++ Specifications

General

Brand	JIYI
Model	K++
Category	Controller
Language	English
