16
STEP 9 STEP 10
Lastly, connect the wires from the han-
dlebar post to the monitor, make sure
your pins are aligned within the wires
and you hear a click for each one. Se-
cure the monitor to the bracket using
the screws found in the back of the
monitor.
Attach the right and left handrails to the
swing arms using two inner hex bolts,
spring washers and arc washers for
each side.
