Johnson Controls 100 Series Engineering Guide

JOHNSON CONTROLS
20
FORM100.50-EG12 (918)
MODEL SIZE 70 75 80 90 105
EVAPORATOR COIL
Size (square feet) 56.9 56.9 56.9 56.9 56.9
Number of Rows/Fins per Inch 4/17 3/17 3/17 3/17 5/17
Tube Diameter/Surface
3/8 inch/
enhanced
3/8 inch/
enhanced
3/8 inch/
enhanced
3/8 inch/
enhanced
3/8 inch/
enhanced
CONDENSER COIL (R-410A)
Size (square feet) 164 164 164 164 164
Number of Rows/Fins per Inch 1/21 1/21 1/21 1/21 1/21
Tube Diameter/Surface
1mm micro
channel
1mm micro
channel
1mm micro
channel
1mm micro
channel
1mm micro
channel
CONDENSER FANS
Quantity 6 6 6 6 6
Type Prop. Prop. Prop. Prop. Prop.
Diameter (inch) 36 36 36 36 36
Power (HP each) 2 2 2 2 2
FILTERS - 2-INCH THROWAWAY (PRE-FILTER POSITION)
Quantity 10/15 10/15 10/15 12/18 12/18
Size (length x width) (inch) 25x16/25x20 25x16/25x20 25x16/25x20 25x16/25x20 25x16/25x20
Total Filter Face Area (square feet) 77.1 77.1 77.1 92.5 92.5
FILTERS - 2-INCH CLEANABLE (PRE-FILTER POSITION)
Quantity 10/15 10/15 10/15 12/18 12/18
Size (length x width) (inch) 25x16/25x20 25x16/25x20 25x16/25x20 25x16/25x20 25x16/25x20
Total Filter Face Area (square feet) 77.1 77.1 77.1 92.5 92.5
FILTERS - 2-INCH PLEATED, 30% EFFICIENT (PRE-FILTER POSITION) (MERV 8)
Quantity 10/15 10/15 10/15 12/18 12/18
Size (length x width) (inch) 25x16/25x20 25x16/25x20 25x16/25x20 25x16/25x20 25x16/25x20
Total Filter Face Area (square feet) 77.1 77.1 77.1 92.5 92.5
FILTERS - 12-INCH RIGID 65%, 2-INCH 30% PRE-FILTER (PRE-FILTER POSITION) (MERV 11)
Quantity 2/8/9 2/8/9 2/8/9 8/12 8/12
Size (length x width) (inch)
16x20/25x16/
25x20
16x20/25x16/
25x20
16x20/25x16/
25x20
25x16/25x20 25x16/25x20
Total Filter Face Area (square feet) 55.8 55.8 55.8 61.6 61.6
FILTERS - 12-INCH RIGID 95%, 2-INCH 30% PRE-FILTER (PRE-FILTER POSITION) (MERV 14)
Quantity 2/8/9 2/8/9 2/8/9 8/12 8/12
Size (length x width) (inch)
16x20/25x16/
25x20
16x20/25x16/
25x20
16x20/25x16/
25x20
25x16/25x20 25x16/25x20
Total Filter Face Area (square feet) 55.8 55.8 55.8 61.6 61.6
FILTERS - 2-INCH CARBON (PRE-FILTER POSITION) (MERV8)
Quantity 10/15 10/15 10/15 12/18 12/18
Size (length x width) (inch)
16x20/25x16/
25x20
25x16/25x20 25x16/25x20 25x16/25x20 25x16/25x20
Total Filter Face Area (square feet) 77.1 77.1 77.1 92.5 92.5
FILTERS - 12-INCH RIGID 95% IN POST-FILTER POSITION (MERV 14)
Quantity 2/7/9 2/7/9 2/7/9 7/12 7/12
Size (length x width) (inch)
16x20/25x16/
25x20
16x20/25x16/
25x20
16x20/25x16/
25x20
25x16/25x20 25x16/25x20
Total Filter Face Area (square feet) 55.1 55.1 55.1 61.1 61.1
Physical Data (Cont'd)
TABLE 3 - PHYSICAL DATA – MODELS 70–105 (CONT'D)
