JOHNSON CONTROLS
22
FORM100.50-EG12 (918)
Weight Data
TABLE 5 - APPROXIMATE BASE OPERATING WEIGHTS (LBS)
MODEL SIZE 70 75 80 90 105
Approximate Unit Weight 10461 10433 10449 10799 10935
NOTES
1. Unit base weights include the following features: sheet metal, control panels, refrigerant, compressors, condenser assemblies, mini-
mum capacity supply fan, and 2-inch throwaway lter.
2. Base weights shown represent approximate operating weights and have a ±10% accuracy. To calculate weight for a specic congura-
tion, use YORKworks or contact a Johnson Controls sales representative.
TABLE 6 - COMPONENT WEIGHTS (LBS)
MODEL SIZE 70 75 80 90 105
CABINET
Sheet Metal 6994 6994 6994 6913 6913
Control Panel 200 200 200 200 200
REFRIGERANT
Refrigerant Charge (R-410A) 125 103 106 110 130.4
COMPRESSORS
Compressor 1 159 135 135 227 146
Compressor 2 159 135 135 227 320
Compressor 3 159 135 135 227 146
Compressor 4 159 135 135 227 320
Compressor 5 159 143 143 227 146
Compressor 6 159 143 143 227 320
CONDENSER ASSEMBLY
Coils
Condenser Coils¹ 616 616 616 616 616
Condenser Motors/Fans
Condenser Motors, 2HP 460/208-230 300 300 300 300 300
Condenser Fans 60 60 60 60 60
Condenser Fan Grilles 60 60 60 60 60
SUPPLY FAN
Comefri 28-25 FC Class II 496 496 496
- -
Comefri 32 AF Class I 649 649 649 649 649
Comefri 32 AF Class II 694 694 694 694 694
Isolators 20 20 20 20 20
DUAL DIRECT DRIVE PLENUM (DDP) FAN SKIDS WITHOUT MOTOR
Frame 215T DDP 402-9-100/120
386.04/397.92Frame 254T DDP 402-9-100/120
Frame 256T DDP 402-9-100/120
Frame 284T DDP 402-9-100/120
394.55/406.43
Frame 286T DDP 402-9-100/120
Frame 324T DDP 402-9-100/120
412.35/424.22
Frame 326T DDP 402-9-100/120
Frame 364T DDP 402-9-100/120
444.85/456.73
Frame 365T DDP 402-9-100/120
WEG MOTOR (SUPPLY/EXHAUST/RETURN)
5HP 81 81 81 81 81
7.5HP 121 121 121 121 121
10HP 128 128 128 128 128
15HP 212 212 212 212 212
20HP 243 243 243 243 243
25HP 411 411 411 411 411
30HP 449 449 449 449 449
40HP 577 577 577 577 577
