Johnson Controls 100 Series Engineering Guide

57
JOHNSON CONTROLS
FORM 100.50-EG12 (918)
Return Fan Data
TABLE 25 - YPAL070–105: 270 SWSI AIRFOIL FAN
TOTAL STATIC PRESSURE (IWG)
CFM
STD. AIR
1.0 1.5 2.0 2.5 3.0
BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM
16000 5.4 966 7.3 1056 9.2 1139 11.2 1217 13.3 1295
18000 6.6 1041 8.6 1126 8.6 1126 12.9 1277 16.1 1618
20000 7.9 1119 10.2 1198 12.5 1272 14.9 1342 18.8 1709
22000 9.6 1199 12.0 1273 14.5 1343 17.1 1410 21.7 1803
24000 11.5 1283 14.0 1351 16.8 1417 19.5 1481 24.9 1900
26000 13.7 1369 16.4 1430 19.3 1493 22.2 1554 25.1 1611
28000 16.2 1456 19.0 1512 22.0 1571 25.2 1629 28.4 1684
30000 19.0 1544 22.0 1597 25.1 1651 28.5 1705 31.9 1759
32000 22.2 1633 25.4 1683 28.6 1733 32.1 1784 35.7 1835
34000 25.7 1723 29.1 1770 32.5 1817 36.1 1864 39.8 1912
36000 29.7 1813 33.3 1859 36.9 1902
NOTE: For performance at operating points not included in these tables, consult your local Johnson Controls representative.
TABLE 26 - RETURN FAN PERFORMANCE
FAN TYPE 2X270
YPAL070–080 X
YPAL090–105 X
