51
JOHNSON CONTROLS
FORM 100.50-EG12 (918)
Supply Fan Data
TABLE 14 - YPAL070–080: 28X25 FORWARD-CURVED FAN
TOTAL STATIC PRESSURE (IWG)
CFM
STD. AIR
1.0 2.0 3.0 4.0 5.0 6.0
BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM
18,000 513 10.0 616 13.9
20,000 520 11.7 619 15.9 717 20.8
22,000 527 13.6 629 18.3 712 22.9 808 28.9
24,000 537 15.8 637 20.9 720 25.9 795 31.1
26,000 549 18.3 643 23.6 729 29.1 801 34.5
28,000 562 21.2 651 26.6 736 32.6 810 38.5
30,000 574 24.2 662 30.1 742 36.3 819 42.8
32,000 585 27.4 674 34.0 750 40.3 825 47.2
34,000 597 30.9 686 38.2 760 44.8
NOTE: For performance at operating points not included in these tables, consult your local Johnson Controls representative.
TABLE 15 - YPAL070–105: 32-INCH AIRFOIL FAN
TOTAL STATIC PRESSURE (IWG)
CFM
STD. AIR
1.0 2.0 3.0 4.0 5.0 6.0
BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM
18,000 937 12.8 1046 17.0 1149 21.7 1249 26.8
20,000 970 14.6 1071 18.9 1168 23.7 1261 28.8
22,000 906 12.4 1006 16.6 1101 21.1 1192 26.0 1280 31.2
24,000 951 14.5 1046 18.9 1136 23.6 1222 28.7 1305 34.0
26,000 900 12.4 998 16.8 1088 21.5 1174 26.4 1255 31.7 1334 37.2
28,000 954 14.8 1047 19.5 1133 24.4 1214 29.6 1292 35.0 1367 40.7
30,000 1008 17.4 1097 22.4 1179 27.6 1256 33.1 1331 38.7 1402 44.6
32,000 1064 20.5 1148 25.8 1226 31.2 1300 36.9 1372 42.8 1440 48.9
YPAL090–105 Only
34,000 1119 23.8 1200 29.4 1275 35.2 1346 41.1 1414 47.3 1481 53.6
36,000 1176 27.6 1252 33.5 1324 39.5 1393 45.7 1459 52.1 1523 58.7
NOTE: For performance at operating points not included in these tables, consult your local Johnson Controls representative.
