Exhaust Fan Data
EXHAUST FAN MOTOR SIZING INSTRUCTIONS
In order to determine the proper exhaust fan motor size, add the return duct static pres-
sure to the appropriate damper pressure drop value in Table 16 on page 53 to get the
total static pressure applied to the exhaust fan. Based on the exhaust fan airflow and total
static pressure, determine the brake horsepower (BHP) and RPM of the exhaust fan.
TABLE 22 - DUAL 18 X 18 FORWARD-CURVED FAN
TOTAL STATIC PRESSURE (IWG)
CFM
STD. AIR
0.25 0.50 0.75 1.00 1.25 1.50
BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM
6000 0.4 291 0.7 398 1.1 501 1.6 596 2.1 683 2.7 763
8000 0.7 316 1.1 406 1.5 485 1.9 566 2.4 643 3.0 717
10000 1.2 349 1.6 429 2.1 499 2.5 562 3.0 627 3.6 691
12000 1.9 392 2.3 456 2.9 522 3.4 581 3.9 635 4.5 688
14000 2.8 435 3.3 491 3.9 549 4.5 605 5.1 656 5.7 704
16000 3.9 476 4.6 533 5.1 579 5.9 631 6.6 681 7.3 727
18000 5.2 517 6.2 577 6.7 619 7.4 661 8.3 707 9.1 752
20000 7.0 560 8.0 619 8.8 662 9.4 698 10.2 737 11.2 779
22000 9.1 604 10.1 660 11.3 706 12.0 740 12.7 773 13.6 809
24000 11.7 648 12.7 701 14.0 748
26000 14.7 693
NOTE: For performance at operating points not included in these tables, consult your local Johnson Controls representative.
TABLE 23 - EXHAUST FAN PERFORMANCE
FAN TYPE 18X18 20X18
YPAL070–080 X X
YPAL090–105 X X
TABLE 24 - DUAL 20 X 18 FORWARD-CURVED FAN
TOTAL STATIC PRESSURE (IWG)
CFM
STD. AIR
0.25 0.50 0.75 1.00 1.25 1.50
BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM
12000 1.3 295 1.9 373 2.5 445 3.2 514 3.9 577 4.6 635
14000 1.9 318 2.5 388 3.2 453 3.9 515 4.7 574 5.5 630
16000 2.6 344 3.3 407 4.1 466 4.9 522 5.7 576 6.6 629
18000 3.5 371 4.3 429 5.1 483 6.0 535 6.9 584 7.8 633
20000 4.6 399 5.4 453 6.4 503 7.3 551 8.3 597 9.3 642
22000 5.9 428 6.8 478 7.8 525 8.8 570 9.9 613 11.0 654
24000 7.5 458 8.5 505 9.5 549 10.6 591 11.7 631 12.9 670
26000 9.4 488 10.4 532 11.5 574 12.7 613 13.9 652 15.1 689
28000 11.5 519 12.6 560 13.8 600 15.0 637 16.3 673 17.6 709
30000 13.9 551 15.2 589 16.4 626 17.7 662 19.0 697 20.4 730
32000 16.7 583 18.1 618 19.4 654 20.7 688 22.1 721 23.6 753
34000 19.9 615 21.3 648 22.7 682 24.1 715 25.6 746
36000 23.4 647 24.9 679 26.4 710 27.9 742
NOTE: For performance at operating points not included in these tables, consult your local Johnson Controls representative.
