Johnson Controls 100 Series Engineering Guide

JOHNSON CONTROLS
50
FORM100.50-EG12 (918)
Heating Performance Data – Gas/Electric Heat
GAS HEATING
TABLE 12 - GAS HEAT PERFORMANCE DATA
Unit
Gas Input Capacity
(Btu/hr x 1000)
Maximum Output Capacity
(Btu/hr x 1000)
Airflow
Minimum
Temp. Rise
(°F)
70–80
375 300 7,500 10–40
750 600 11,150 20–50
1125 900 15,150 25–55
90–105
375 300 6,950 10–40
750 600 11,150 20–50
1125 900 15,150 25–55
NOTE
Gas valve rated for 0.5 psig. If gas pressure greater than 0.5 psig then a gas pressure regulator is required.
Minimum gas pressure is 4.5 iwg.
ELECTRIC HEATING
TABLE 13 - ELECTRIC HEAT PERFORMANCE DATA
UNIT SIZE (KW)
HEAT CAPACITY
(MBH)
AIRFLOW MIN
(CFM)
MAX TEMP RISE
(°F)
70–80 TON
80 273 10,000 25
108 369 12,000 28
150 512 14,000 34
200 683 15,000 42
90–105 TON
108 369 12,000 28
150 512 14,000 34
200 683 15,000 42
250 854 16,000 49
