Johnson Controls 100 Series Engineering Guide

55
JOHNSON CONTROLS
FORM 100.50-EG12 (918)
Electric Heat Pressure Drops
TABLE 20 - ELECTRIC HEAT AIR PRESSURE DROPS
TABLE 21 - ELECTRIC HEATER SIZE AVAILABILITY BY UNIT SIZE
MODEL 80kW 108kW 150kW* 200kW* 250kW*
YPAL070–080 X X X X
YPAL090–105** X X X X
*150–250kW electric heat not available in 200-230V congurations.
**For 208V YPAL105, contact Johnson Controls.
MODEL
AIRFLOW
CFM STD.
AIR
ELECTRIC HEATER AIR PRESSURE DROP (IWG)
80 KW 108 KW 150 KW 200 KW 250 KW
YPAL070–080
14,000 0.02 0.03 0.04 0.05
16,000 0.03 0.04 0.06 0.07
18,000 0.04 0.06 0.07 0.09
20,000 0.05 0.07 0.09 0.11
22,000 0.06 0.08 0.11 0.13
24,000 0.07 0.10 0.13 0.16
26,000 0.08 0.12 0.15 0.19
28,000 0.09 0.13 0.18 0.22
30,000 0.11 0.15 0.20 0.25
32,000 0.12 0.17 0.23 0.28
YPAL090–105
18,000 0.06 0.07 0.09 0.12
20,000 0.07 0.09 0.11 0.15
22,000 0.08 0.11 0.13 0.19
24,000 0.10 0.13 0.16 0.22
26,000 0.12 0.15 0.19 0.26
28,000 0.13 0.18 0.22 0.30
30,000 0.15 0.20 0.25 0.35
32,000 0.17 0.23 0.28 0.39
34,000 0.20 0.26 0.32 0.44
36,000 0.22 0.29 0.36 0.50
