JOHNSON CONTROLS
24
FORM100.50-EG12 (918)
MODEL SIZE 70 75 80 90 105
POWER EXHAUST (CONT'D)
Comefri 15-15 FC Class R 194 194 194 194 194
Comefri 15-15 FC Class II 280 280 280 280 280
Comefri 18-18 FC Class R 306 306 306 306 306
Comefri 18-18 FC Class II 396 396 396 396 396
Return Fan 490 490 490 490 490
EXHAUST FAN MOTOR
5HP 87 87 87 87 87
7.5HP 120 120 120 120 120
10HP 144 144 144 144 144
15HP 217 217 217 217 217
20HP 237 237 237 237 237
25HP 330 330 330 330 330
30HP 372 372 372 372 372
RETURN FAN MOTOR
5HP 87 87 87 87 87
7.5HP 120 120 120 120 120
10HP 144 144 144 144 144
15HP 217 217 217 217 217
20HP 237 237 237 237 237
25HP 330 330 330 330 330
30HP 372 372 372 372 372
40HP 474 474 474 474 474
EXHAUST FAN VFD
5–10 HP
22 22 22 22 22
15–25 HP
51 51 51 51 51
30–40 HP
66 66 66 66 66
EXHAUST DAMPER
Barometric, (24 x 76) 45 45 45 55 55
Modulating, (24 x 76) 75 75 75 90 90
Fan skid 46 46 46 49 49
Exhaust Hood 91 91 91 102 102
HEATING OPTIONS
Electric Heat - 80kW (Max) 430 430 430 430 430
Electric Heat - 108kW (Max) 450 450 450 450 450
Electric Heat - 150kW (Max) 470 470 470 470 470
Electric Heat - 200kW (Max) 490 490 490 490 490
Electric Heat - 250kW (Max) 510 510 510 510 510
Gas Heat - 375 MBH (Max) 162 162 162 162 162
Gas Heat - 750 MBH (Max) 324 324 324 324 324
Gas Heat - 1125 MBH (Max) 486 486 486 486 486
Hot Water Coil 318 318 318 318 318
Steam Coil 236 236 236 236 236
MISC.
Open Perimeter Curb 577 577 577 615 615
Enclosed Perimeter Curb 1020 1020 1020 1040 1040
Condenser Section Sheet Metal 2767 2767 2767 2767 2767
0–100% AMS
2
125 125 125 140 140
Condenser Section Wire Guards 102 102 102 102 102
Louvered Panel Guard 465 465 465 465 465
NOTES
1. The weight given is the total weight of all eight aluminum coils and all eight copper coils, respectively. Indicates that particular option is
not available with that model size.
2. The 0–100% AMS option needs some predetermined minimum airow rate to work.
TABLE 6 – COMPONENT WEIGHTS (LBS) (CONT'D)
Weight Data (Cont’d)
