Johnson Controls 100 Series Engineering Guide

69
JOHNSON CONTROLS
FORM 100.50-EG12 (918)
TABLE 34 - THREE PHASE POWER SUPPLY CONDUCTOR SIZE RANGE
70–75 TON UNITS
SUPPLY
VOLTAGE
SINGLE POINT
TB
SINGLE POINT
DISCONNECT
DUAL POINT TB
TB1
TB2
208V (2-in.) 250 kcmil-500 kcmil (2-in.) 2 AWG-500 kcmil 4 AWG-500 kcmil 6 AWG-350 kcmil
230V (2-in.) 250 kcmil-500 kcmil (2-in.) 2 AWG-500 kcmil 6 AWG-400 kcmil 6 AWG-350 kcmil
380V-60 (2-in.) 3/0-250 kcmil 4 AWG-500 kcmil 6 AWG-400 kcmil 14 AWG-2/0
460V (2-in.) 3/0-250 kcmil 4 AWG-500 kcmil 14 AWG-2/0 14 AWG-2/0
575V 6 AWG-400 kcmil 6 AWG-350 kcmil 14 AWG-2/0 14 AWG-2/0
80 TON UNITS
SUPPLY
VOLTAGE
SINGLE POINT
TB
SINGLE POINT
DISCONNECT
DUAL POINT TB
TB1
TB2
208V (2-in.) 2/0-400 kcmil (2-in.) 2 AWG-500 kcmil (2-in.) 2 AWG-500 kcmil 6 AWG-350 kcmil
230V (2-in.) 250 kcmil-500 kcmil (2-in.) 2 AWG-500 kcmil 4 AWG-500 kcmil 6 AWG-350 kcmil
380V-60 (2-in.) 3/0-250 kcmil 4 AWG-500 kcmil 6 AWG-400 kcmil 14 AWG-2/0
460V (2-in.) 3/0-250 kcmil 4 AWG-500 kcmil 6 AWG-400 kcmil 14 AWG-2/0
575V (2-in.) 3/0-250 kcmil 6 AWG-350 kcmil 14 AWG-2/0 14 AWG-2/0
90–105 TON UNITS
SUPPLY
VOLTAGE
SINGLE POINT
TB
SINGLE POINT
DISCONNECT
DUAL POINT TB
TB1
TB2
208V (2-in.) 2/0-400 kcmil (2-in.) 2 AWG-500 kcmil (2-in.) 2 AWG-500 kcmil 4 AWG-600 kcmil
230V (2-in.) 2/0-400 kcmil (2-in.) 2 AWG-500 kcmil (2-in.) 2 AWG-500 kcmil 4 AWG-600 kcmil
380V-60 (2-in.) 3/0-250 kcmil 4 AWG-500 kcmil 4 AWG-500 kcmil 14 AWG-2/0
460V (2-in.) 3/0-250 kcmil 4 AWG-500 kcmil 6 AWG-400 kcmil 14 AWG-2/0
575V (2-in.) 3/0-250 kcmil 6 AWG-350 kcmil 14 AWG-2/0 14 AWG-2/0
