LEFT SUPPLY / LEFT RETURN
FIGURE 18 - GENERAL ARRANGEMENT DRAWING
NOTES
1. 10’ Clearance Minimal Over The Top
of the Condensing Unit.
2. Only One Adjacent Wall Can Exceed
Unit Height.
3. 12’ Clearance Required to Adjacent
Units
4. 8’ Service Access Recommended on
One Side.
5. Economizer and Exhaust Hoods,
Where Applicable, are Folded Inside Unit for Shipment.
SECTION DESCRIPTIONS: EE = Economizer FE = Fan Exhaust MB = Mixing Box _F = Filter Segments CC = Cooling Coils FS = Supply Fan DP = Discharge Plenum CO = Condenser Section CP = Control Panel
12’ - 5”
10’
43’ - 4 3/4”
11’ - 5 13/16”
7’ - 8 7/8”
General Arrangement Drawing – 90–105 Ton Models (Cont'd)
