Johnson Controls B1HA036 User Manual

341849-YIM-A-0108
12 Johnson Controls Unitary Products
FIGURE 4 - Dimensions and Clearances
CLEARANCES
(Minimum)
Front 12"
Back 0"
Left Side (Filter Access) 24"
Right Side 24"
Below Unit
1
0"
Above Unit
2
36"
1. Units may be installed on combustible floors made from wood or
class A, B or C roof covering material.
2. Units must be installed outdoors. Overhanging structures or
shrubs should not obstruct outdoor air discharge outlet.
CONDENSATE
DRAIN
" NPTI
LOW VOLTAGE
CONN.
" DIA. KNOCK
-
HIGH VOLTAGE
CONN.
" x " DIA.
KNOCKOUT
FRONT
6
OUTDOOR
COIL
15
4
BACK
SIDE RETURN
AIR OPENING
SIDE SUPPLY
AIR OPENING
BOTTOM RETURN
AIR OPENING
15
2
1
1
1
15
BOTTOM SUPPLY
AIR OPENING
2
LOW VOLTAGE CONN.
" DIA. KNOCKOUT
HIGH VOLTAGE CONN.
" DIA. KNOCKOUT
FRONT
ELECTRICAL/FILTER
SERVICE ACCESS
COMPARTMENT PANEL
(OVERALL)
(OVERALL)
4
1
2
All dimensions are in inches. They are
subject to change without notice. Certified
dimensions will be provided upon request.
UNIT CONDENSATE
CONNECTION
" NPTI
(TRAP REQUIRED)
(OVERALL)
SIDE SUPPLY
AIR OPENING
SIDE RETURN
AIR OPENING
COMPRESSOR
SERVICE ACCESS
COMPARTMENT PANEL
HIGH VOLTAGE CONN.
" DIA. KNOCKOUT
HIGH VOLTAGE CONN.
" DIA. KNOCKOUT
REFRIGERANT
CONNECTIONS
“A”
UNIT SIZE
DIMENSION
“A”
036 - 042
33
048 - 060
41
(For Condenser Air Discharge)
49
