TABLE 4: Electrical Data (Heat Pump / Electric Heat)
Size Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Electric Heat Option
MCA
(Amps)
Max Fuse/
Breaker Size
1
(Amps)
Max HACR
2
Breaker Size
RLA LRA FLA FLA Model Stages kW Amps
036 208/230-3-60 10.9 78.0 1.1 3.5
2NH04501025 1 7.5/10.0
3
20.8/24.1 44.3/48.3 45/50 45/50
2NH04501525 1 11.3/15.0
3
31.3/36.1 57.3/63.3 60/70 60/70
042 208/230-3-60 12.8 88.0 1.1 3.5
2NH04501025 1 7.5/10.0
3
20.8/24.1 46.9/50.7 50/60 50/60
2NH04501525 1 11.3/15.0
3
31.3/36.1 59.7/65.7 60/70 60/70
048 208/230-3-60 14.1 105.0 1.5 4.0
2NP04501025 1 7.5/10.0
3
20.8/24.1 49.2/53.2 50/60 50/60
2NP04501525 1 11.3/15.0
3
31.3/36.1 62.2/68.2 70/70 70/70
2NP04502025 2 15.0/20.0
3
41.7/48.1 75.3/83.3 80/90 80/90
2NH04502525 2 18.8/25.0
3
52.1/60.1 88.3/98.3 90/100 90/100
060 208/230-3-60 16.0 125.0 1.5 7.0
2NH04501025 1 7.5/10.0
3
20.8/24.1 54.6/58.6 60/60 60/60
2NH04501525 1 11.3/15.0
3
31.3/36.1 67.6/73.6 70/80 70/80
2NH04502025 2 15.0/20.0
3
41.7/48.1 80.7/88.7 90/90 90/90
2NH04502525 2 18.8/25.0
3
52.1/60.1 93.7/103.7 100/110 100/110
036 460-3-60 5.8 40.0 0.6 1.8
2NH04501046 1 10.0
4
12.8 24.6 25 25
2NH04501546 1 15.0
4
18.0 32.2 35 35
042 460-3-60 5.8 42.0 0.6 1.8
2NH04501046 1 10.0
4
12.0 24.7 25 25
2NH04501546 1 15.0
4
18.0 32.2 35 35
048 460-3-60 7.1 55.0 0.8 2.0
2NP04501046 1 10.0
4
12.0 26.7 30 30
2NH04501546 1 15.0
4
18.0 34.2 35 35
2NH04502046 2 20.0
4
24.1 41.7 45 45
2NH04502546 2 25.0
4
30.1 49.3 50 50
060 460-3-60 8.0 67.0 0.8 3.5
2NH04501046 1 10.0
4
12.0 29.4 30 30
2NH04501546 1 15.0
4
18.0 36.9 40 40
2NP04502046 2 20.0
4
24.1 44.4 45 45
2NP04502546 2 25.0
4
30.1 51.9 60 60
036 575-3-60 4.5 32.0 0.4 1.5
2NH04501058 1 10.0
5
9.6 19.6 20 20
2NH04501558 1 15.0
5
14.4 25.6 30 30
042 575-3-60 5.8 44.0 0.4 1.5
2NH04501058 1 10.0
5
9.6 21.1 25 25
2NH04501558 1 15.0
5
14.4 27.2 30 30
048 575-3-60 5.6 44.0 0.6 1.6
2NH04501058 1 10.0
5
9.6 21.3 25 25
2NH04501558 1 15.0
5
14.4 27.3 30 30
2NH04502058 2 20.0
5
19.2 33.3 35 35
2NH04502558 2 25.0
5
24.1 39.3 40 40
060 575-3-60 6.4 50.0 0.6 2.8
2NH04501058 1 10.0
5
9.6 23.4 25 25
2NH04501558 1 15.0
5
14.4 29.5 30 30
2NP04502058 2 20.0
5
19.2 35.5 40 40
2NP04502558 2 25.0
5
24.1 41.5 45 45
1. Dual element, time delay type.
2. Standard circuit breakers may be used in Canada and on applications over 60 amps where the heaters are separately fused.
3. KW listed is for 240 volts, use table at top of next page for 208 or 230 volts.
4. KW listed is for 480 volts, use table at top of next page for 460 volts.
5. KW listed is for 600 volts, use table at top of next page for 575 volts.
TABLE 5: Electrical Data (Basic Unit)
Size Volt
Voltage
Limitations
1
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
MCA
(Amps)
Max Fuse
Size
2
(Amps)
Max HACR
Breaker Size
Unit Power
Factor
Transformer
Size (VA)
Min. Max. RLA LRA FLA FLA
036 208/230-3-60 187 253 10.9 78.0 1.1 3.5 18.2 25 25 .96 75
042 208/230-3-60 187 253 12.8 88.0 1.1 3.5 20.6 25 25 .96 75
048 208/230-3-60 187 253 14.1 105.0 1.5 4.0 23.1 30 30 .96 75
060 208/230-3-60 187 253 16.0 125.0 1.5 7.0 28.5 40 40 .96 75
036 460-3-60 414 504 5.8 40.0 0.6 1.8 9.6 15 15 .96 75
042 460-3-60 414 504 5.8 42.0 0.6 1.8 9.7 15 15 .96 75
048 460-3-60 414 504 7.1 55.0 0.8 2.0 11.7 15 15 .96 75
060 460-3-60 414 504 8.0 67.0 0.8 3.5 14.3 20 20 .96 75
036 575-3-60 518 630 4.5 32.0 0.4 1.5 7.6 15 15 .96 75
042 575-3-60 518 630 5.8 44.0 0.4 1.5 9.1 15 15 .96 75
048 575-3-60 518 630 5.6 44.0 0.6 1.6 9.3 15 15 .96 75
060 575-3-60 518 630 6.4 50.0 0.6 2.8 11.4 15 15 .96 75
1. Rated in accordance with ARI Standard 110, utilization range “A”.
2. Dual element, time delay type.
