341849-YIM-A-0108
Johnson Controls Unitary Products 3
GENERAL
YORK Model B1HA units are factory assembled heat
pumps designed for outdoor installation on a rooftop or
a slab. Field-installed electric heater accessories are
available to provide supplemental electric heat com-
bined with electric cooling and heating.
The units are completely assembled on rigid, remov-
able base rails. All piping, refrigerant charge, and elec-
trical wiring is factory installed and tested. The units
require only electric power and duct connections at the
point of installation.
The electric heaters have nickel-chrome resistance wire
elements and utilize single point power connection.
INSPECTION
As soon as a unit is received, it should be inspected for
possible damage during transit. If damage is evident,
the extent of the damage should be noted on the car-
rier's freight bill. A separate request for inspection by
the carrier's agent should be made in writing.
REFERENCE
Additional information on the design, installation, oper-
ation and service of this equipment is available in the
following reference forms:
• 341849 - General Installation
• 035-16605-003 - Electric Heater Accessory
REPLACEMENT PARTS
Contact your local York
®
parts distribution center for
authorized replacement parts.
PRODUCT NOMENCLATURE
This product must be installed in strict compli-
ance with the enclosed installation instructions
and any applicable local, state, and national
codes including, but not limited to, building,
electrical, and mechanical codes.
Improper installation may create a condition
where the operation of the product could cause
personal injury or property damage.
De-energize the electrical power to the unit
before attempting to inspect, repair or perform
maintenance to the unit.
B 1 H A A
PRODUCT NOMENCLATURE
PRODUCT GENERATION
1 = NEW or Current Design
PRODUCT CATEGORY
B = Single Package Heat Pumps
(Air Cooled)
PRODUCT IDENTIFIER
HA = Heat Pump (10 SEER)
30 6 2 5
FACTORY
INSTALLED ELECTRIC HEAT
A = No Electric Heat Installed
VOLTAGE CODE
25 = 208/230-3-60
46 = 460-3-60
58 = 575-3-60
NOMINAL COOLING
CAPACITY (MBH)
036 = 36,000 BTUH
042 = 42,000 BTUH
048 = 48,000 BTUH
060 = 60,000 BTUH
To Next Page
