8 Johnson Controls Unitary Products
Electric Heat
Correction
Factors
Nominal Voltage Voltage
kW. Capacity
Multiplier
240
208 .75
230 .92
480 460 .92
600 575 .92
TABLE 6: Side & Bottom Supply Air Blower Performance 230/460/575 Volts
Size
Blower
Speed
External Static Pressure (Inch Water Gauge)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0 1.1
CFM W CFM W CFM W CFM W CFM W CFM W CFM W CFM W CFM W CFM W CFM W
036
High - - - - - - - - 1414 617 1317 688 1219 660 1116 533 1013 507 910 480 - -
Medium - - - - 1472 647 1394 626 1297 495 1199 465 1102 435 985 397 - - - - - -
Low 1462 526 1400 506 1337 486 1275 467 1167 440 1100 414 1012 387 - - - - - - - -
042
High - - - - - - - - 1697 740 1580 706 1463 672 1339 640 1216 608 1092 576 - -
Medium - - - - - - 1673 830 1566 594 1439 558 1322 522 1182 476 - - - - - -
Low - - 1680 607 1608 584 1630 660 1425 528 1320 496 1214 464 1050 420 - - - - - -
048
High - - - - - - 1947 882 1867 857 1786 832 1706 807 1637 782 1569 757 1500 732 - -
Medium 1876 792 1829 772 1783 753 1736 733 1668 706 1599 680 1531 653 1434 622 1337 591 1240 560 - -
Low 1544 620 1508 610 1472 600 1436 590 1375 573 1313 557 1252 540 - - - - - - - -
036
High - - - - - - 2499 1290 2391 1233 2283 1177 2175 1120 2067 1080 1958 1040 1850 1000 - -
Medium - - 2454 1163 2387 1117 2320 1070 2229 1023 2137 977 2046 930 1950 887 1854 843 1758 800 - -
Low 2242 1090 2201 1053 2161 1017 2120 980 2041 927 1962 873 1883 820 1797 787 1711 753 1625 720 - -
TABLE 7: Side & Bottom Supply Air Blower Performance 208 Volts
Size
Blower
Speed
External Static Pressure (Inch Water Gauge)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0 1.1
CFM W CFM W CFM W CFM W CFM W CFM W CFM W CFM W CFM W CFM W CFM W
036
High - - - - 1440 608 1381 571 1273 656 1185 530 1097 604 1004 480 912 456 - - - -
Medium 1465 631 1395 512 1325 492 1255 473 1167 446 1079 419 952 392 - - - - - - - -
Low 1316 473 1260 455 1204 438 1148 420 1069 396 990 372 911 348 - - - - - - - -
042
High - - - - 1728 725 1633 697 1527 666 1422 636 1317 606 1205 676 1094 547 - - - -
Medium - - 1674 614 1590 590 1506 567 1400 636 1296 602 1190 470 1063 428 - - - - - -
Low 1679 867 1612 646 1449 526 1377 504 1282 476 1188 447 1093 418 - - - - - - - -
048
High - - 1982 870 1939 850 1897 830 1813 800 1728 770 1644 740 1559 707 1474 673 1389 640 - -
Medium 1694 690 1662 673 1629 657 1597 640 1542 623 1486 607 1431 590 1336 563 1240 537 - - - -
Low 1385 520 1349 510 1312 500 1276 490 1235 480 - - - - - - - - - - - -
036
High - - - - 2450 1213 2366 1165 2282 1117 2198 1068 2114 1020 1989 993 1864 967 1739 940 - -
Medium 2339 1170 2275 1118 2211 1067 2147 1015 2083 963 2019 912 1955 860 1854 824 1753 788 1652 752 - -
Low 1929 940 1877 903 1824 867 1772 830 1720 793 1667 757 1615 720 1586 706 1557 691 1528 677 - -
TABLE 8: Additional Static Pressure Resistance
1
,
2
Description
Resistance, IWG
CFM
500 600 700 800 900 1000 1100 1200 1300 1400 1500 1600 1700 1800 1900 2000
Wet Indoor Coil 0.01 0.01 0.01 0.02 0.02 0.03 0.03 0.04 0.04 0.04 0.04 0.04 0.05 0.05 0.06 0.07
Economizer 0.00 0.00 0.00 0.01 0.01 0.01 0.01 0.02 0.03 0.04 0.05 0.06 0.07 0.07 0.08 0.08
Filter/Frame Kit 0.01 0.02 0.02 0.02 0.02 0.02 0.03 0.03 0.03 0.03 0.04 0.05 0.05 0.06 0.06 0.07
Electric Heat 0.02 0.03 0.03 0.03 0.04 0.04 0.05 0.06 0.07 0.08 0.09 0.10 0.01 0.11 0.11 0.12
1. Deduct these resistance values from the available external static pressures shown in the respective Blower Performance Table.
2. The pressure thru the economizer is greater for 100% outdoor air than for 100% return air. If the resistance of the return air duct system is less than
0.25 IWG, the unit will deliver less CFM during full economizer operation.
