Table 7: Device diagnostics
Parameter Description
Release Mode Indicates the release.
Security Version A number associated with a new firmware image. The CWa uses
this number to indicate whether a Firmware Update is required.
Model An internal code number the CWa uses to determine the correct
firmware image to use to update the CWCVT.
Note: The values in this table do not update automatically. The values are updated when the
table is first viewed and when the Refresh button at the bottom of the table is pressed.
Wi-Fi diagnostics
Table 8: Wi-Fi diagnostics
Parameter Description
RSSI The Receive Signal Strength Indication of the Wi-Fi signal. Values
less than -80 may lead to a poor connection.
Channel The current channel that the Wi-Fi connection uses.
Max Tx Power The maximum Tx power in dBm that the CWCVT transmits data.
Station Count A count of the number of Wi-Fi Stations (Clients) connected to
the CWCVT's access point.
Station List A list of the MAC addresses of the Wi-Fi Station devices
connected to the CWCVT's access point.
Station Disconnects A running count of the number of times a Wi-Fi client
disconnects and then reconnects to the access point. Could be
an indication of poor Wi-Fi signal.
Note: The values in this table do not update automatically. The values are updated when the
table is first viewed and when the Refresh button at the bottom of the table is pressed. These
values reset to 0 on every power cycle.
Note: These values do not update when connected to the CWCVT in BLE Router mode.
BLE diagnostics
Table 9: BLE diagnostics
Parameter Description
RSSI The Receive Signal Strength Indication of the Bluetooth signal.
Values less than -80 may lead to a poor connection.
Connection Count A running count of the number of times a BLE Host controller
connected and re-connected to the CWCVT.
Connection Interval The amount of time between two BLE connection events in units
of 1.25 ms. Smaller numbers improve performance, but increases
power consumption.
Tx Packet Count A running count of the number of message packets sent to the BLE
Host controller.
Rx Packet Count A running count of the number of message packets received from
the BLE Host controller.
17CWCVT Wireless MS/TP Converter User Guide
