CWCVT pages
The CWCVT contains several pages of information that you can navigate with the A button. The
CWCVT remembers the last page viewed and re-displays that page on a power cycle.
At-a-glance page
The at-a-glance page displays large colored blocks that indicate the connection status of the
wireless and MS/TP connections. This page makes it easier to view the connection status when you
work on a ladder or at a distance of the controller that the CWCVT is plugged into.
The Wireless Status indicates the following states:
Table 1: Wireless Status states
State Display
background
color
Description
No Conn Black No connection. The CWCVT is not wirelessly connected to a
device.
BLE Conn'd Blue Connected. The CWCVT is wirelessly connected to a mobile
device or computer in BLE Router mode.
Note: The CWCVT supports only one bluetooth connec-
tion at a time.
Wi-Fi Conn'd White Connected. The CWCVT is currently connected to one or
more devices in Wi-Fi AP Router mode.
Note: The CWCVT supports up to four Wi-Fi connections
simultaneously.
The MS/TP Status indicates the following states:
Table 2: MS/TP Status states
State Display
background
color
Description
Auto Black The CWCVT is in an Auto-baud state. The CWCVT listens to the
MS/TP bus and joins the token ring if activity is detected.
Sole Yellow The CWCVT is the sole Manager device and does not detect
any other MS/TP Manager controllers on the bus.
Live Green The CWCVT is actively participating in the MS/TP token loop
and one or more MS/TP Manager controllers are on the bus.
Overview page
The Overview page displays the following general information about the wireless and MS/TP
connections:
• Wireless connection status
• MS/TP connection status
• Active MS/TP Baud Rate
• The active MS/TP device address being used by the CWCVT
7CWCVT Wireless MS/TP Converter User Guide
