Fig. 20 Lock setting
4 Installation Instructions
4.1 Parts and Dimension of Wired Controller
Fig. 21 Dimension of wired controller
Fig. 22 Parts of wired controller
No. 1 2 3
Name
Panel of wired
controller
Screw M4h25
Soleplate of wired
controller
Quantity 1 3 1
31 2
unit˖mm
