Johnson Controls F4-CV Series User Manual

Table 13: CV Series controllers technical specifications
Description
Universal Input (UI) Resolution/
Configurable Output (CO) Accuracy
UI Analog Input Mode: 15-bit resolution on UIs
CO Analog Output Mode: 0–10 VDC ± 200 mV
Air Pressure Differential Sensor Range: -2 in. to 2 in. H2O
Performance Characteristics:
Typical Accuracy at ambient operating conditions: +/- 0.5 % in. H2O full scale
Typical accuracy at zero (null) pressure is +/- 0.0006 in. H2O
Actuator Rating 4 N·m (35 lb·in) minimum shaft length = 44 mm (1-3/4 in.) (if provided)
Terminations Inputs/Outputs: Pluggable Screw Terminal
FC Bus, SA Bus, and Supply Power: 4-Wire and 2-Wire Pluggable Screw Terminal Blocks
SA Bus Modular Ports: RJ-12 6-Pin Modular Jacks
Note: The FC Bus Terminal and FC Bus Port are only available on the CVM models
Mounting Mounts to damper shaft using single set screw and to duct with single mounting screw
Housing Enclosure material: ABS and polycarbonate UL94 5VB; Self-extinguishing
Protection Class: IP20 (IEC529)
Dimensions
(Height x Width x Depth)
165 mm x 125 mm x 73 mm (6.5 in. x 4.92 in. x 2.9 in.)
Center of Output Hub to Center of Captive Spacer: 135 mm (5-5/16 in.)
Weight 0.69 kg (1.52 lb)
Compliance United States:
UL Listed, File E107041, CCN PAZX, UL 916, Energy Management Equipment.
FCC Compliant to CFR47, Part 15, Subpart B, Class A.
Suitable for Use in Other Environmental Air Space (Plenums) in Accordance with Section
300.22(C) of the National Electrical Code.
Canada:
UL Listed, File E107041, CCN PAZX7, CAN/CSA C22.2 No. 205, Signal Equipment.
Industry Canada Compliant, ICES-003
Europe:
CE Mark – Johnson Controls declares that this product is in compliance with the essential
requirements and other relevant provisions of the EMC Directive and RoHS Directive.
Australia and New Zealand:
RCM Mark, Australia/NZ Emissions Compliant.
BACnet International: BACnet Testing Laboratories
™
(BTL) Protocol Revision 18 Listed
and Certified BACnet Advanced Application Controller (B-AAC), based on ANSI/ASHRAE
135-2016
The performance specifications are nominal and conform to acceptable industry standard. For application at conditions beyond
these specifications, consult the local Johnson Controls office. Johnson Controls shall not be liable for damages resulting from
misapplication or misuse of its products.
