Table 6: SA/FC Bus Device Address Descriptions
for MS/TP Controllers
Use on DescriptionDevice
Address
Used for MS/TP master devices (FX-PC
controllers) that are hardwired to an SA Bus
or FC Bus.
4 to 127
(Switch
128 Off)
Reserved addresses for wired slave devices
(not for use on FX-PC controllers).
Note: FX-PCG controllers ship with switch 128
ON and the remaining address switches off
rendering the controllers wired slave devices,
which do not operate on MS/TP buses.
0 to 3
(Switch
128 ON)
Valid for MS/TP Master controllers on wireless
FC Buses only.
Note: Do not connect a controller with switch
128 ON to an active (hard-wired) SA or FC
bus. When a controller with switch 128 ON
and a device address from 4 to 127 is
connected to a wired field bus, the entire field
bus is rendered inoperable until the controller
is disconnected or switch 128 is set to Off.
4 to 127
(Switch
128 ON)
19FX-PCG16 General Purpose Programmable Controller Installation Instructions
