Hardware Installation—Installing the IFC-1010/2020
25
Cable
Part Number 75142
15-position
Receptacle
15-position
Plug
cbl75142
Figure 16: Cable, Part Number 75142
Cable
Part Number 75142
16th Pin
15-position
Receptacle
Front View
(Chassis in Cabinet)
cablecn
Figure 17: Cable, Part Number 75142 Connected to the ICA-4L
